VFD、Servo 및 다양한 모터 드라이버 생산에 집중
연간 판매량 900,000개 이상
전력 범위: 0.4kw ~ 2000kw, 전압 범위: 110v ~ 10000v
서비스 유통 네트워크는 전 세계를 커버합니다.
| 원래 장소: | 상하이, 중국 |
|---|---|
| 브랜드 이름: | ZONCN Vfd |
| 인증: | CE |
| 모델 번호: | SP600T-11KY-4 |
| 최소 주문 수량: | 1 단위 |
| 포장 세부 사항: | 상자 포장 |
| 배달 시간: | 7-30 일 근무일 |
| 지불 조건: | T/T, Western Union, PayPal |
| 공급 능력: | 한 달에 10 만 단위 |
| 재료: | 금속 | 전압: | 400v±15% |
|---|---|---|---|
| 보증: | 18 개월 | 평가 된 전력: | 11kw VFD |
| 통신 방식: | RS485 | 내장된 PID: | 프로세스 제어 폐쇄 루프 제어 시스템을 쉽게 실현합니다. |
| 속도 안정성 정확도: | ± 0.2% | 고도: | 1000m 이하 |
| 습도: | 95%RH 미만, 결로되지 않음 | 진동: | 5.9m/s2(0.6g) 미만 |
Air compressors integrator inverter 11KW 15HP 380V
Specification
The ZONCN SP600 series frequency inverter VFD has become the preferred solution for industrial energy-saving transformation, thanks to its vector control technology, air compressor-specific algorithms and high-reliability design. Its intelligent functions, such as automatic sleep mode and fault early warning, along with flexible expansion capability, can significantly improve equipment operation efficiency and reduce maintenance costs. It is particularly suitable for small and medium-sized manufacturing enterprises and air compressor integrators. For detailed technical documentation or customized solutions, please contact VFD ZONCN Technology through its official website or local distributors.
Company Profile
As a high-tech enterprise deeply rooted in electrical drive and industrial automation, 2ONoN has always upheld exhibitions as a pivotal window to engage with the global market. The company actively participates in dozens of premier domestic and international industry events annually, forging a multi-dimensional communication network that encompasses core technology demonstrations, market demand alignment, and the expansion of international collaboration.
Applications
Firstly, high integration efficiency, space-saving and loss reduction. The SP600 series adopts an all-plastic plus sheet metal base plate design, which highly integrates core components such as inverters, DC reactors, PT100/PTC detection circuits, and 24V power supplies. It supports both wall-mounted and floor-mounted installation, greatly reducing the equipment footprint. Meanwhile, it minimizes energy loss and signal interference during line transmission (a common issue in split-type solutions) and improves system response efficiency.
Secondly, easy operation and reduced implementation costs. The product features a plug-in error-proof terminal design, simplifying wiring and commissioning. Equipped with air compressor-specific software, it enables one-click startup without the need for complex parameter configuration, significantly shortening the installation and commissioning cycle.
Thirdly, reliable operation and hassle-free maintenance. It comes with built-in multiple protection circuits (against motor overheating, overcurrent, overvoltage, etc.) and can perform real-time monitoring of key parameters such as air compressor head temperature and system pressure, providing early warnings of potential faults. Additionally, the integrated design reduces reliance on external components, and the selection of industrial-grade components extends the equipment's fault-free operation time.
Fourthly, outstanding energy efficiency and adaptability to diverse working conditions. Leveraging dedicated energy-saving algorithms and variable frequency speed control technology, it can dynamically adjust motor speed based on air demand load, avoiding energy waste caused by idling of fixed-frequency air compressors. It achieves significant energy-saving effects in both full-load and partial-load scenarios. Moreover, it is adaptable to a wide temperature operating range (-10℃ to 40℃), meeting the needs of various industrial scenarios.
